Overview

This portfolio is a production‑ready, bilingual site built with FastAPI and served over HTTPS on AWS. The goal was to keep the app simple, secure, and fully automated from infra to deployment.

User‑facing features

• Bilingual routing (EN/ES): landing at / and CV at /cv
• Rich project pages with Markdown and code blocks (this page included)
• Collapsible project cards, clean centered layout, and enable/disable UI buttons via config
• Certifications section with each item linking to its Credly page (name and badge clickable)
• Freelance page at /freelance with calendar/hour selection and rate; “Book now” pre‑fills the contact flow

Scheduling, availability and bookings

• Weekly schedule enforced on client and server:
• Mon–Thu 18–23, Fri 15–23, Sat/Sun 0–23 (configurable in YAML)
• Past dates/hours are disabled (client) and filtered server‑side
• Blocked dates configurable in YAML and enforced end‑to‑end
• Double‑booking prevention with a slots table (unique date+hour)
• Atomic booking creation: insert booking + slots within a transaction; on conflict returns 409

Admin panel (/admin)

• Basic Auth protected (ADMINUSER/ADMINPASS via environment variables)
• Bookings:
• List/filter/search bookings; update status (new/contacted/confirmed/cancelled)
• Export CSV; per‑booking ICS export (calendar)
• Config editor (/admin/config):
• Sections visibility toggles
• Hero buttons: enable/disable and URL per button (writes to the correct YAML source)
• Certifications: enable/disable and Credly URL per item
• Diagnostics panel: shows detected config files, hero button source file per key, certifications source, and build metadata (image, SHA, time)

Configuration model (YAML, last‑wins merge)

• The app merges python/config.yaml with files in python/config.d/*.yaml
• Keys:
• sections.* — toggles to show/hide pieces of the UI
• hero_buttons.* — enable/URL/labels per button (contact/freelance/github/linkedin/certifications/CV)
• certifications[] — list with name, badge, url, enabled, and order
• freelance.* — rate, schedule, and blocked dates
• Admin config writes back to the originating YAML (tracked per key), so edits persist and are source‑of‑truth

Data persistence

• SQLite database with two tables:
• bookings — core booking metadata + serialized selections
• slots — one row per reserved (date, hour), primary key (date,hour)
• Writable data directory is auto‑resolved; in production the app uses /data mounted from the host

Architecture

• App: FastAPI + Uvicorn (listens on port 8000 inside the container)
• Reverse proxy: Caddy publishes 80/443, terminates TLS (Let’s Encrypt), redirects www → apex, adds HSTS, and proxies to the app
• Containerization: one image for the app; Caddy runs as a separate container in the same Docker network

Infrastructure (Terraform)

• EC2 (Amazon Linux 2023) in default VPC
• Elastic IP associated to the instance
• Security group allowing 22/80/443
• Route 53 hosted zone for adrianmagarola.com:
• A record (apex) → Elastic IP
• www CNAME → apex
• Remote state backend: S3 (+ DynamoDB lock)

Terraform state (sketch)

terraform {
  backend "s3" {}
}

resource "aws_instance" "web" { /* Amazon Linux 2023, key pair, SG */ }
resource "aws_eip" "web" { instance = aws_instance.web.id }
resource "aws_route53_zone" "primary" { name = var.domain_name }
resource "aws_route53_record" "root_a" { /* apex A → EIP */ }
resource "aws_route53_record" "www"    { /* CNAME www → apex */ }

CI/CD (GitHub Actions)

• Provision EC2 (Terraform): initializes backend and applies infra
• Build and Deploy to EC2 (Docker): builds/pushes image and deploys via SSH
• Prunes containers/images/build cache to free space on small instances
• Sends the Caddyfile base64‑encoded to avoid SSH wrapper injections
• Mounts volumes on EC2 host:
• /opt/portfolio/data → container /data with PORTFOLIODATADIR=/data (SQLite persistence)
• /opt/portfolio/config.d → container /app/python/config.d (config persistence)
• Seeds missing config files from the image; force‑syncs 50‑certifications.yaml (with backup) to align URLs/structure
• Exposes build metadata to the app: APPBUILDSHA, APPBUILDIMAGE, APPBUILDTIME (visible in admin Diagnostics)

Caddyfile (essentials)

{
  email admin@adrianmagarola.com
}

www.adrianmagarola.com {
  redir https://adrianmagarola.com{uri} 301
}

adrianmagarola.com {
  encode gzip
  header {
    Strict-Transport-Security "max-age=31536000; includeSubDomains; preload"
  }
  reverse_proxy portfolio:8000
}

Security and operability

• TLS with automatic certificates (Let’s Encrypt)
• HSTS and www → apex redirect
• Admin protected by Basic Auth (set ADMINUSER/ADMINPASS)
• App runs unprivileged; Caddy owns ports 80/443
• Disk housekeeping for predictable deploys

Endpoints (selected)

• GET / — landing (EN/ES)
• GET /cv — CV page; certifications column with Credly links
• GET /freelance — booking UI
• POST /api/bookings — atomic booking (enforces schedule, blocked dates, past slots)

Result

• Live: https://adrianmagarola.com
• Repo: https://github.com/amagarola/portfolio

Terraform Infrastructure with YAML Configs

📌 Overview

This project provides a centralized configuration module for managing multi-environment infrastructure using YAML templates.

Instead of hardcoding parameters across multiple Terraform workloads, all configurations are defined in a single yaml-config module that other workload modules can reference.

Key Concept: The system uses a hierarchical merge strategy where base configurations are defined once, and each environment (dev, qa, pre, prod) only overrides what's different. This eliminates duplication and keeps infrastructure definitions DRY.

---

🗂️ Project Structure

terraform/
├── yaml-config/                    # Central configuration module
│   ├── main.tf                     # Module entry point
│   ├── outputs.tf                  # Exposes hierarchical configs
│   ├── variables.tf                # Module inputs
│   ├── modules/
│   │   └── yaml-config/            # Core merge logic
│   │       ├── main.tf
│   │       └── variables.tf
│   └── config/
│       └── env/
│           ├── ec2.yaml            # Base EC2 config
│           ├── storage.yaml        # Base S3 config
│           ├── database.yaml       # Base RDS config
│           ├── network.yaml        # Base VPC config
│           ├── security.yaml       # Base security groups
│           ├── eks.yaml            # Base EKS config
│           ├── dev/                # Dev overrides
│           ├── qa/                 # QA overrides
│           ├── pre/                # Pre-prod overrides
│           └── prod/               # Production overrides
│
├── workload-ec2/                   # EC2 workload module
├── workload-storage/               # S3 workload module
├── workload-database/              # RDS workload module
├── workload-network/               # VPC/networking module
├── workload-security/              # Security Groups module
└── workload-eks/                   # EKS cluster module

---

⚙️ How It Works

1. YAML Structure

Each YAML file follows this structure:

context:
  environment: "${env}"

terraform:
  vars:
    storage:                        # Resource type
      s3_buckets:                   # Resource category
        first-s3:                   # Resource key
          name: "first-s3-${env}"   # Properties
          versioning: true
          encryption: true

2. Hierarchical Merging

• Base config (config/env/*.yaml) applies to all environments
• Environment overrides (config/env/{env}/*.yaml) merge on top
• yaml-config module uses templatefile() to interpolate variables
• Result: Clean, merged configuration per environment

3. Data Flow

Base YAML + Env YAML → yaml-config → Merged Config → Workload Modules → AWS Resources

Example:

storage.yaml + qa/storage.yaml → merge → module.yaml_config.env.qa.storage → for_each → S3 buckets

---

🚀 Usage Example

In a Workload Module

Step 1: Reference yaml-config

module "yaml_config" {
  source      = "../yaml-config"
  environment = var.environment
}

Step 2: Access configurations

locals {
  s3_buckets = try(
    module.yaml_config.env[var.environment].storage.s3_buckets,
    {}
  )
}

Step 3: Create resources dynamically

resource "aws_s3_bucket" "this" {
  for_each = local.s3_buckets
  bucket   = each.value.name
  # ... other properties from YAML
}

Adding New Resources

No Terraform code changes required!

---

• Edit config/env/storage.yaml (base definition)
• Override in config/env/qa/storage.yaml if needed
• Run terraform apply -var="environment=qa"
• Resources auto-created via for_each ✨

✅ Benefits

• DRY Principle → Define once, override only differences
• Centralized → Single source of truth
• Dynamic → Auto-scaling with for_each
• Type-safe → Structured YAML schema
• Flexible → Template interpolation (${env})
• Clean separation → Config vs. logic
• Easy auditing → Clear git diffs per environment
